KAWASAKIJET SKIΒ® ULTRAΒ® 310X2014
|
|
Frame
|
Jet Pump
|
|
No |
Part |
Part No |
Notes |
410
|
W-PLAIN-S,5MM |
410S0500 |
|
410A
|
WASHER-PLAIN-SMALL,6MM |
410S0600 |
|
410B
|
WASHER-PLAIN-SMALL,8MM |
410S0800 |
|
610
|
ROLLER,4X8 |
610A0408 |
|
11055
|
BRACKET,PUMP |
11055-3710 |
|
11065
|
CAP |
11065-0888 |
|
13107
|
SHAFT |
13107-0764 |
|
13107A
|
SHAFT |
13107-3804 |
|
13234
|
SHAFT-COMP |
13234-3712 |
|
14091
|
COVER,COOLING TUBE |
14091-3808 |
|
14091A
|
COVER,VANE GUIDE |
14091-3817 |
|
39112
|
RODEND-TIE |
39112-3703 |
|
39112A
|
RODEND-TIE |
39112-3707 |
|
39145
|
TRIM-SEAL |
39145-3809 |
|
43058
|
RING |
43058-3735 |
|
52014
|
ELBOW |
52014-3711 |
|
52014A
|
ELBOW |
52014-3727 |
|
59136
|
NOZZLE-PUMP |
59136-3768 |
|
59255
|
IMPELLER-COMP |
59255-0001 |
|
59266
|
JOINT-BALL |
59266-3710 |
|
59366
|
GRATE |
59366-3724 |
|
59476
|
NOZZLE-STRG |
59476-0063 |
|
59477
|
BUCKET-REVERSE |
59477-0001 |
|
59496
|
VANE-GUIDE |
59496-3767 |
|
92002
|
BOLT,6X25 |
92002-3714 |
|
92002A
|
BOLT,6X30 |
92002-3726 |
|
92009
|
SCREW,6X20 |
92009-3848 |
|
92015
|
NUT,18MM |
92015-1512 |
|
92022
|
WASHER,8.4X23X2.5 |
92022-3744 |
|
92022A
|
WASHER |
92022-567 |
|
92033
|
RING-SNAP |
92033-3730 |
|
92045
|
BEARING-BALL,6303R-6 |
92045-3744 |
|
92045A
|
BEARING-BALL,62/22 2RS |
92045-3745 |
|
92049
|
SEAL-OIL |
92049-3739 |
|
92055
|
RING-O,49.7X2.4 |
92055-0183 |
|
92055A
|
RING-O,12X1.5 |
92055-025 |
|
92055B
|
RING-O,27.7X1.9 |
92055-1272 |
|
92055C
|
RING-O |
92055-3741 |
|
92055D
|
RING-O,66.5X2.0 |
92055-3784 |
|
92093
|
SEAL |
92093-3749 |
|
92139
|
BUSHING |
92139-0767 |
|
92139A
|
BUSHING |
92139-3720 |
|
92150
|
BOLT,SOCKET,6X18 |
92150-3775 |
|
92150A
|
BOLT,8X35 |
92150-3792 |
|
92150B
|
BOLT,FLANGED,8X30 |
92150-3803 |
|
92151
|
BOLT,10X30 |
92151-3706 |
|
92152
|
COLLAR,8.2X11.8X13.5 |
92152-1694 |
|
92152A
|
COLLAR,8.2X11.8X15 |
92152-3703 |
|
92153
|
BOLT,SOCKET,5X30 |
92153-3742 |
|
92154
|
BOLT,FLANGED,8X25 |
92154-3705 |
|
92154A
|
BOLT,BALL,8X30 |
92154-3706 |
|
92154B
|
BOLT,SOCKET,8X15 |
92154-3707 |
|
92154C
|
BOLT,BALL,6MM |
92154-3710 |
|
92154D
|
BOLT,SOCKET,8X18 |
92154-3711 |
|
92200
|
WASHER,8.0X22.0X1.5 |
92200-0174 |
|
92210
|
NUT,6MM |
92210-3789 |
|
|
|
|
