Frame
|
Jet Pump
|
|
No |
Part |
Part No |
Notes |
410
|
WASHER-PLAIN-SMALL,6MM |
410S0600 |
|
410A
|
WASHER-PLAIN-SMALL,8MM |
410S0800 |
|
11012
|
CAP,JET PUMP |
11012-3712 |
|
13107
|
SHAFT,JET PUMP |
13107-3721 |
|
13234
|
SHAFT-COMP,JOINT |
13234-3708 |
|
39145
|
TRIM-SEAL |
39145-3732 |
|
52014
|
ELBOW |
52014-3708 |
|
59136
|
NOZZLE-PUMP |
59136-3716 |
|
59256A
|
IMPELLER |
59256-3723 |
|
59266
|
JOINT-BALL |
59266-3707 |
|
59366
|
GRATE |
59366-3710 |
|
59476
|
NOZZLE-STRG |
59476-3713 |
|
59496
|
VANE-GUIDE |
59496-3703 |
|
92001
|
BOLT,SOCKET,6X11 |
92001-3701 |
|
92001A
|
BOLT,BALL,6MM |
92001-3703 |
|
92002
|
BOLT,6X30 |
92002-3726 |
|
92002A
|
BOLT,6X16 |
92002-3728 |
|
92002B
|
BOLT,SOCKET,8X20 |
92002-3771 |
|
92022
|
WASHER |
92022-567 |
|
92028
|
BUSHING,17X25X15 |
92028-3717 |
|
92045
|
BEARING-BALL,#63032RD |
92045-3706 |
|
92049
|
SEAL-OIL,TCV-25476 |
92049-3711 |
|
92055
|
RING-O,13X1.9 |
92055-1021 |
|
92055A
|
RING-O |
92055-3706 |
|
92093
|
SEAL,JET PUMP |
92093-3739 |
|
92143
|
COLLAR,17.4X25.4X53 |
92143-3708 |
|
92150
|
BOLT,SOCKET,6X18 |
92150-3795 |
|
|
|
|
