KAWASAKIJET SKIΒ® STXΒ®-15F2015
|
|
|
Frame
|
|
Hull Front Fittings
|
|
| No |
Part |
Part No |
Notes |
|
411
|
WASHER-PLAIN,5MM |
411S0500 |
|
|
11051
|
BRACKET |
11051-3766 |
|
|
11053
|
BRACKET |
11053-3752 |
|
|
11056
|
BRACKET,LH |
11056-3715 |
|
|
11056A
|
BRACKET,RH |
11056-3717 |
|
|
13271
|
PLATE |
13271-3897 |
|
|
14073
|
DUCT,HATCH,INNER |
14073-3800 |
|
|
14091C
|
COVER,HATCH,L.GREEN |
14091-3778-777 |
|
|
14092
|
COVER,FRONT DUCT |
14092-0842 |
|
|
27012
|
HOOK |
27012-3855 |
|
|
27016
|
LOCK-ASSY |
27016-0049 |
|
|
35063
|
STAY,MIRROR,RH,F.BLACK |
35063-3709-6Z |
|
|
35063A
|
STAY,MIRROR,LH,F.BLACK |
35063-3710-6Z |
|
|
35063B
|
STAY,MIRROR,LH |
35063-3713 |
|
|
35063C
|
STAY,MIRROR,RH |
35063-3714 |
|
|
39145
|
TRIM-SEAL,L=1380 |
39145-3773 |
|
|
39145A
|
TRIM-SEAL,L=260 |
39145-3789 |
|
|
53009
|
HINGE,HATCH COVER |
53009-3725 |
|
|
56001B
|
MIRROR-ASSY,LH |
56001-0267 |
|
|
56001C
|
MIRROR-ASSY,RH |
56001-0268 |
|
|
92002
|
BOLT,6X25 |
92002-3714 |
|
|
92015
|
NUT,LOCK,6MM |
92015-3766 |
|
|
92015A
|
NUT,6MM |
92015-3767 |
|
|
92022
|
WASHER,6.5X20X1.5 |
92022-3710 |
|
|
92028
|
BUSHING |
92028-3765 |
|
|
92039
|
RIVET |
92039-3714 |
|
|
92039A
|
RIVET |
92039-3747 |
|
|
92043
|
PIN |
92043-0754 |
|
|
92143
|
COLLAR,8.2X14X11.2 |
92143-3724 |
|
|
92150
|
BOLT,6X18 |
92150-3729 |
|
|
92160
|
DAMPER |
92160-3738 |
|
|
92161
|
DAMPER,HATCH |
92161-1581 |
|
|
92161A
|
DAMPER |
92161-3728 |
|
|
92161B
|
DAMPER |
92161-3739 |
|
|
92161C
|
DAMPER |
92161-3747 |
|
|
92161D
|
DAMPER |
92161-3754 |
|
|
92200
|
WASHER,8.5X32X2 |
92200-3786 |
|
|
92210
|
NUT,LOCK,8MM |
92210-3742 |
|
|
92210A
|
NUT,6MM |
92210-3768 |
|
|
|
|
