Frame
|
Hull Fittings
|
|
No |
Part |
Part No |
Notes |
410
|
W-PLAIN-S,3MM |
410S0300 |
|
11012
|
CAP,FIRE EXTINGUISHER |
11012-3766 |
|
11047
|
BRACKET,FUEL FILTER |
11047-3761 |
|
11048
|
BRACKET,HATCH COVER |
11048-3777 |
|
11048A
|
BRACKET,HATCH COVER LOCK |
11048-3778 |
|
11049
|
BRACKET,HANDLE COVER |
11049-3716 |
|
11049A
|
BRACKET |
11049-3717 |
|
11049B
|
BRACKET |
11049-3718 |
|
11049C
|
BRACKET,HATCH COVER |
11049-3736 |
|
11049D
|
BRACKET |
11049-3743 |
|
11050
|
BRACKET,HATCH COVER |
11050-3739 |
|
11065
|
CAP,STEP NUT |
11065-3712 |
|
13107
|
SHAFT,3X32 |
13107-3745 |
|
13244
|
STOPPER-ASSY,HATCH COVER |
13244-3701 |
|
13270
|
PLATE,FIRE EXTINGUISHER |
13270-3729 |
|
13271
|
PLATE |
13271-3738 |
|
14037
|
SCREEN,METER,F.BLACK |
14037-3710-6Z |
|
14073
|
DUCT,FR |
14073-3758 |
|
14090
|
COVER,HATCH,S.YELLOW |
14090-3769-7H |
|
14090A
|
COVER,HANDLE,S.YELLOW |
14090-3770-7H |
|
14090B
|
COVER,CENTER STORAGE,S.YELLOW |
14090-3771-7H |
|
27012
|
HOOK,HATCH COVER LOCK |
27012-3803 |
|
27016
|
LOCK-ASSY,HATCH COVER |
27016-3737 |
|
27016A
|
LOCK-ASSY,STORAGE COVER |
27016-3743 |
|
32085
|
STOPPER,STORAGE LOCK |
32085-3726 |
|
32099
|
CASE,FIRE EXTINGUISHER |
32099-3769 |
|
39012
|
CASE-STORAGE,FR |
39012-3715 |
|
39012A
|
CASE-STORAGE,CNT |
39012-3719 |
|
39012B
|
CASE-STORAGE,RR |
39012-3720 |
|
39043
|
CROSSMEMBER-COMP |
39043-3701 |
|
39145
|
TRIM-SEAL |
39145-3754 |
|
39145A
|
TRIM-SEAL,STORAGE CASE |
39145-3755 |
|
39145B
|
TRIM-SEAL,L=1380 |
39145-3773 |
|
39156A
|
PAD,KNEE,D.BURGUNDY |
39156-3811-MQ |
|
46075
|
GRIP,TAIL,S.YELLOW |
46075-3745-AU |
|
53009
|
HINGE,HATCH COVER |
53009-3725 |
|
56001
|
MIRROR-ASSY,LH,S.YELLOW |
56001-3709-AU |
|
56001A
|
MIRROR-ASSY,RH,S.YELLOW |
56001-3710-AU |
|
59071
|
JOINT |
59071-3743 |
|
92002
|
BOLT,6X25 |
92002-3714 |
|
92002A
|
BOLT,6X40 |
92002-3716 |
|
92002B
|
BOLT,6X20 |
92002-3755 |
|
92002C
|
BOLT,6X12 |
92002-3763 |
|
92009
|
SCREW,5X16 |
92009-3789 |
|
92009A
|
SCREW,6X12 |
92009-3852 |
|
92015
|
NUT,6MM |
92015-3767 |
|
92022
|
WASHER,6.5X20X1.5 |
92022-3710 |
|
92022A
|
WASHER,6.2X20X2 |
92022-3714 |
|
92027
|
COLLAR,6.2X10X10 |
92027-3705 |
|
92033
|
RING-SNAP,2MM |
92033-3711 |
|
92039
|
RIVET,4MM |
92039-3703 |
|
92039A
|
RIVET |
92039-3748 |
|
92039B
|
RIVET |
92039-3755 |
|
92071
|
GROMMET |
92071-3716 |
|
92071A
|
GROMMET |
92071-3812 |
|
92071B
|
GROMMET |
92071-3816 |
|
92143
|
COLLAR |
92143-3763 |
|
92150
|
BOLT,5X14 |
92150-3702 |
|
92150A
|
BOLT,6X18 |
92150-3729 |
|
92160
|
DAMPER |
92160-3814 |
|
92160A
|
DAMPER |
92160-3821 |
|
92160B
|
DAMPER |
92160-3839 |
|
92160C
|
DAMPER |
92160-3840 |
|
92160D
|
DAMPER,MIRROR,LH,F.BLACK |
92160-3869-6Z |
|
92160E
|
DAMPER,MIRROR,RH,F.BLACK |
92160-3870-6Z |
|
92160F
|
DAMPER,HANDLE COVER |
92160-3897 |
|
92191
|
TUBE |
92191-3867 |
|
92200
|
WASHER,5.9X16X1.5 |
92200-3714 |
|
|
|
|
