Please select company, model and Year.
|
|
KAWASAKIJET SKIΒ® ULTRAΒ® 310X2014
|
|
Frame
|
Hull
|
|
No |
Part |
Part No |
Notes |
311
|
NUT-HEX,6MM |
311R0600 |
|
410
|
WASHER-PLAIN-SMALL,6MM |
410S0600 |
|
411
|
WASHER-PLAIN,5MM |
411S0500 |
|
411A
|
WASHER-PLAIN,8MM |
411S0800 |
|
11051
|
BRACKET,BREATHER-BILGE |
11051-3802 |
|
11052
|
BRACKET,RR DUCT |
11052-3712 |
|
11056
|
BRACKET,WATER MUFFLER |
11056-3722 |
|
11060
|
GASKET,U HOOK,RR |
11060-3800 |
|
11060A
|
GASKET,DRAIN PLUG |
11060-3801 |
|
11061
|
GASKET,BATTERY COVER |
11061-3754 |
|
13227
|
HOUSING,DRAIN PLUG,F.BLACK |
13227-3721-6Z |
|
13270
|
PLATE |
13270-3860 |
|
13271
|
PLATE |
13271-3724 |
|
13280
|
HOLDER,EXHAUST VALVE |
13280-3718 |
|
14073A
|
DUCT |
14073-3805 |
|
14073B
|
DUCT,L=1000 |
14073-3836 |
|
14073
|
DUCT,L=800 |
14073-3804 |
|
14091
|
COVER,ECU |
14091-3786 |
|
14091A
|
COVER,BATTERY |
14091-3809 |
|
14091B
|
COVER,STORAGE CASE |
14091-3819 |
|
16188
|
FLOAT |
16188-0032 |
|
27012
|
HOOK |
27012-3797 |
|
27012A
|
HOOK |
27012-3816 |
|
27012B
|
HOOK |
27012-3821 |
|
32152
|
PIPE |
32152-3749 |
|
32154
|
PIPE,DRIVE SHAFT |
32154-3714 |
|
32155
|
PIPE,COOLING |
32155-1511 |
|
39031
|
CAP-END |
39031-3704 |
|
59426
|
HULL-COMP,BLACK/EBONY |
59426-0003-43D |
|
59437
|
STABILIZER,LH,F.BLACK |
59437-3749-6Z |
|
59437A
|
STABILIZER,RH,F.BLACK |
59437-3750-6Z |
|
59446
|
COVER-JET PUMP |
59446-3760 |
|
92002
|
BOLT,6X20 |
92002-3755 |
|
92009
|
SCREW,TAPPING,4X16 |
92009-3849 |
|
92015
|
NUT,20MM |
92015-1589 |
|
92015A
|
NUT,FLANGED,8MM |
92015-1933 |
|
92022
|
WASHER,20.3X36X2.3 |
92022-1116 |
|
92022A
|
WASHER |
92022-567 |
|
92026
|
SPACER |
92026-0780 |
|
92027
|
COLLAR,6.2X10X10 |
92027-3705 |
|
92037
|
CLAMP |
92037-3009 |
|
92037A
|
CLAMP |
92037-3738 |
|
92039
|
RIVET |
92039-3741 |
|
92039A
|
RIVET |
92039-3755 |
|
92039B
|
RIVET |
92039-3775 |
|
92039C
|
RIVET |
92039-3785 |
|
92039D
|
RIVET |
92039-3788 |
|
92066
|
PLUG |
92066-1306 |
|
92066A
|
PLUG,RR,DRAIN,F.BLACK |
92066-3783-6Z |
|
92072
|
BAND,314X18 |
92072-3814 |
|
92072A
|
BAND,L=608.22 |
92072-3884 |
|
92093
|
SEAL |
92093-3720 |
|
92093A
|
SEAL |
92093-3784 |
|
92150
|
BOLT,SOCKET,6X18 |
92150-3775 |
|
92154
|
BOLT,FLANGED,8X55 |
92154-1123 |
|
92161
|
DAMPER |
92161-3769 |
|
92192
|
TUBE,39X51X78 |
92192-3756 |
|
92200
|
WASHER |
92200-3779 |
|
|
|
|
