KAWASAKI
550 SX
1995

Spare Part Category
Show me all the part categories of the model
KAWASAKI - 550 SX 1995 - Frame - Hull
Frame
Hull
No Part Part No Notes
156 BOLT-WP,6X25 156R0625
157 BOLT-WSP,5X20 157R0520
221 SCREW-CSK-CROS,6X16 221R0616
225 SCREW-PAN-WSP-CROS,6X16 225R0616
225A SCREW-PAN-WSP-CROS,6X20 225R0620
411 WASHER-PLAIN,5MM 411S0500
461 WASHER-SPRING,5MM 461S0500
11012 CAP,FIRE EXTINGUISHER 11012-3741
11046 BRACKET,REAR BUMPER 11046-3829
11046A BRACKET,CONTROL PANEL COVER 11046-3835
11047 BRACKET,DECK,PAD,LH 11047-3703
11047A BRACKET,DECK,PAD,RH 11047-3704
27012 HOOK 27012-501
27012A HOOK 27012-502
39027 BUMPER-FRONT 39027-3713
39028 BUMPER-REAR 39028-3705
39087 PAD-HANDLE,POLE 39087-3701
39156 PAD,DECK,LH 39156-3731
39156A PAD,DECK,RH 39156-3732
39156B PAD,CONTROL PANEL COVER 39156-3733
53004 MAT,DECK 53004-3731
59251 HULL,LH,EXTENSION,JET WHITE 59251-3006-8C
59251A HULL,RH,EXTENSION,JET WHITE 59251-3713-8C
59346 DETENT 59346-504
59426 HULL-COMP,JET WHITE 59426-3777-8C
59437 STABILIZER 59437-3002
59446 COVER-JET PUMP 59446-3718
92009 SCREW,5X22 92009-3761
92009A SCREW,4X8 92009-3770
92011 SCREW,TAPPING 92011-561
92015 NUT,FLANGED,5MM 92015-3768
92015A NUT,CAP,5MM 92015-3802
92022 WASHER,5X16X1.5 92022-3041
92039 RIVET 92039-3002
92039A RIVET 92039-3712
92039B RIVET 92039-3733
92065 GASKET,ENGINE HOOD 92065-539
92066 PLUG 92066-3731
92066A PLUG 92066-3734
92075 DAMPER 92075-3719
92093 SEAL,OSR70X82X7.5 92093-3704
92143 COLLAR 92143-3711
92200 WASHER 92200-3706
