KAWASAKI
1200 STX-R
2003

Spare Part Category
Show me all the part categories of the model
KAWASAKI - 1200 STX-R 2003 - Frame - Hull
Frame
Hull
No Part Part No Notes
410 WASHER-PLAIN-SMALL,6MM 410S0600
411 WASHER-PLAIN,5MM 411S0500
11051 BRACKET,BREATHER-BILGE 11051-3802
11052 BRACKET 11052-3765
11060 GASKET,U HOOK,RR 11060-3800
11060A GASKET,DRAIN PLUG 11060-3801
13227 HOUSING,DRAIN PLUG 13227-3711
13270 PLATE 13270-3860
13271 PLATE 13271-3724
13271B PLATE 13271-3858
13271C PLATE,REAR TOWING HOOK 13271-3859
13280 HOLDER 13280-3703
13280A HOLDER,FUEL FILTER 13280-3705
13280B HOLDER,EXHAUST VALVE 13280-3718
14073 DUCT 14073-3781
27012 HOOK 27012-3787
27012A HOOK 27012-3797
27012B HOOK,BOW,F.BLACK 27012-3822-6Z
27012C HOOK,REAR TOWING,F.BLACK 27012-3836-6Z
39031 CAP-END 39031-3704
39145 TRIM-SEAL,L=1412 39145-3748
39145A TRIM-SEAL,JET PUMP COVER 39145-3768
59426A HULL-COMP,J.WHITE 59426-3933-8C
59437 STABILIZER,RIGHT BASE,F.BLACK 59437-3725-6Z
59437A STABILIZER,RIGHT WING,F.BLACK 59437-3727-6Z
59437B STABILIZER,LEFT BASE,F.BLACK 59437-3728-6Z
59437C STABILIZER,LEFT WING,F.BLACK 59437-3730-6Z
59446 COVER-JET PUMP 59446-3754
92002 BOLT,6X20 92002-3755
92009 SCREW,TAPPING,4X16 92009-3849
92015 NUT,FLANGED,8MM 92015-3709
92022 WASHER 92022-567
92039 RIVET,4.8MM 92039-3719
92039A RIVET 92039-3755
92066 PLUG,RR,DRAIN 92066-3744
92071 GROMMET 92071-3812
92072 BAND,314X18 92072-3814
92072A BAND,BATTERY 92072-3841
92093 SEAL 92093-3720
92093A SEAL 92093-3765
92143 COLLAR 92143-3749
92150 BOLT,SOCKET,6X18 92150-3775
92150A BOLT,SOCKET,6X25 92150-3823
92150B BOLT,SOCKET,6X40 92150-3847
92151 BOLT,SOCKET,M6,SHOULDER 92151-3746
92152 COLLAR 92152-3731
92160 DAMPER 92160-3840
92160A DAMPER,40X25 92160-3865
92200 WASHER,6.5X14.5X1.5 92200-3775
92200A WASHER 92200-3779
