KAWASAKI
800 SX-R
2011

Spare Part Category
Show me all the part categories of the model
KAWASAKI - 800 SX-R 2011 - Body Parts - Handle Pole
Body Parts
Handle Pole
No Part Part No Notes
315 NUT-HEX-FINE,14MM 315R1400
317 NUT-HEX-SMALL 317R0800
410 WASHER-PLAIN-SMALL,6MM 410S0600
411 WASHER-PLAIN,14MM 411S1400
461 WASHER-SPRING,6MM 461S0600
550 PIN-COTTER,4X40 550S4040
555 PIN-SPRING,3X25 555B0325
671 O RING,40MM 671B2540
11053 BRACKET 11053-3741
11053A BRACKET 11053-3749
11055 BRACKET 11055-3715
11065 CAP 11065-3726
13091 HOLDER 13091-3774
13107 SHAFT 13107-3781
13271 PLATE 13271-3845
13271A PLATE 13271-3882
14044 HOLDER-CABLE 14044-3716
14090 COVER,HANDLE POLE,S.RED 14090-3708-H1
14090A COVER,HANDLE POLE,C.L.GREEN 14090-3708-367
16031 FLOAT,HANDLE POLE 16031-3951
16031A FLOAT,HANDLE POLE 16031-3952
27012 HOOK 27012-3859
35009 BRACE 35009-3712
39100 POLE-COMP-HANDLE,S.RED 39100-3717-H1
39100A POLE-COMP-HANDLE,C.L.GREEN 39100-3717-367
59266 JOINT-BALL 59266-3707
92002 BOLT,6X16 92002-3728
92004 STUD 92004-3728
92004A STUD,8X25 92004-3756
92009 SCREW,5X16 92009-3797
92009A SCREW,5X16 92009-3868
92015 NUT,CASTLE,18MM 92015-3006
92015A NUT,6MM 92015-3767
92015B NUT,CLIP,5MM 92015-3830
92022 WASHER,CLAMP 92022-3014
92022A WASHER,8.5X34X3 92022-3746
92022B WASHER 92022-567
92022C WASHER 92022-571
92028 BUSHING 92028-3743
92028A BUSHING,STEERING 92028-3752
92037 CLAMP,LEAD WIRE 92037-3007
92043 PIN,STOPPER 92043-3754
92071 GROMMET 92071-3788
92072 BAND,L=188.85 92072-0105
92145 SPRING 92145-3720
92150 BOLT,6X20 92150-3758
92151 BOLT,SOCKET,6X16 92151-3770
92160 DAMPER 92160-3790
92161 DAMPER 92161-3743
92200 WASHER,3.5X12X1 92200-3723
92200A WASHER,20.5X80X3 92200-3725
