Frame
|
|
HULL/ENGINE HOOD (JS550-A8)
|
|
| No |
Part |
Part No |
Notes |
|
1
|
HULL-COMP,JET WHITE |
59426-3759-8C |
|
|
2
|
HULL,LH,EXTENSION,JET WHITE |
59251-3006-8C |
|
|
3
|
HULL,RH,EXTENSION,JET WHITE |
59251-3005-8C |
|
|
4
|
COVER,DASHBOARD |
14025-3706 |
|
|
5
|
RIVET,4MM |
92039-3703 |
|
|
6
|
CAP |
11012-3721 |
|
|
7
|
SEAL-OIL |
92049-3709 |
|
|
8
|
HOOK |
27012-501 |
|
|
9
|
HOOK |
27012-502 |
|
|
10
|
SCREW,TAPPING |
92011-561 |
|
|
11
|
BUSHING |
92028-3734 |
|
|
12
|
DAMPER,FUEL TANK |
92075-521 |
|
|
13
|
DAMPER,MUFFLER |
92075-522 |
|
|
14
|
GASKET,ENGINE HOOD |
92065-539 |
|
|
15
|
MAT |
59131-502 |
|
|
16
|
BUMPER |
59201-3691 |
|
|
17
|
DETENT |
59346-504 |
|
|
18
|
STABILIZER |
59437-3002 |
|
|
19
|
WASHER,5X16X1.5 |
92022-3041 |
|
|
20
|
RIVET |
92039-3002 |
|
|
21
|
TEMPLATE,STABILIZER |
99969-0560 |
|
|
22
|
HOOD-COMP-ENGINE,JET WHITE |
59456-3001-8C |
|
|
23
|
BAND,HOOD |
92072-501 |
|
|
24
|
BOLT,6X30 |
92001-3022 |
|
|
25
|
WASHER,BAND |
92022-509 |
|
|
26
|
BRACKET,PLATE |
59086-501 |
|
|
27
|
GROMMET |
92071-056 |
|
|
28
|
LEVER |
13168-3701 |
|
|
29
|
DETENT |
59346-503 |
|
|
30
|
SCREW |
92011-562 |
|
|
31
|
HINGE |
53009-503 |
|
|
32
|
MAT,DECK FIN,RH |
53004-3723 |
|
|
33
|
MAT,DECK FIN,LH |
53004-3724 |
|
|
34
|
MAT,DASHBOARD,RH |
53004-3726 |
|
|
35
|
MAT,DASHBOARD,LH |
53004-3727 |
|
|
36
|
MAT,DASHBOARD COVER |
53004-3725 |
|
|
37
|
DAMPER,69X16T |
92075-3710 |
|
|
38
|
GRIP,HULL |
46075-3701 |
|
|
39
|
NUT |
92015-3779 |
|
|
|
|
