KAWASAKI
JS440
1983

Spare Part Category
Show me all the part categories of the model
KAWASAKI - JS440 1983 - Electrical - GENERATOR (JS440-A6)
Electrical
GENERATOR (JS440-A6)
No Part Part No Notes
1 COVER-GENERATOR 14031-3705
2 "O" RING 92055-521
3 BREATHER 14069-3709
4 "0" RING 92055-515
5 BOLT 8X50 110R0850
6 NUT 8MM 311R0800
7 WASHER 410S0800
8 WASHER SPRING 8MM 461S0800
9 UNAVAILABLE IN PRICE BOOK 551S0612
10 FLYWHEEL ASSY,MAGNETO 21050-3015
11 STATOR ASSY,MAGNETO 21003-3009
12 COIL,CHARGE 59031-3001
13 SCREW 5X34 92011-530
14 COIL,EXCITING 21049-3006
15 COIL,PULSING 59026-3006
16 COLLAR-COIL 92027-3008
17 SCREW 92009-3006
18 SCREW 4X6 92011-559
19 CLAMP 92037-520
20 SCREW 4X8 92011-560
21 CLAMP 92037-547
22 HARNESS,MAGNETO 26001-3006
23 SCREW PAN HEAD 5X20 220B0520
24 WASHER SPRING 5MM 461F0500
25 WASHER 92022-544
26 CAP 11012-3012
27 GROMMET 92071-3001
28 TUBE,10X345 92059-3032
29 CAP-MAGNETO HARNESS 59176-517-YR
30 CONNECTOR,CORD 59221-506
31 "O" RING 92055-520
32 BOLT 6X35 110R0635
33 WASHER 410S0600
34 WIRE-LEAD,L=300 26011-3006
35 BOLT,8X80 92001-3011
36 WASHER 410S0800
37 WASHER SPRING 8MM 461S0800
