KAWASAKI
650 SX
1990

Spare Part Category
Show me all the part categories of the model
KAWASAKI - 650 SX 1990 - Engine/Transmission - Engine Mount
Engine/Transmission
Engine Mount
No Part Part No Notes
155 BOLT-WSP-SMALL,8X20 155R0820
14044 HOLDER-CABLE 14044-3709
39082 MOUNT-ENGINE 39082-3705
92002 BOLT,10X25 92002-3765
92002A BOLT,10X25 92002-3770
92022 WASHER,32X10.5X4 92022-3023
92025 SHIM,T=0.3MM 92025-3705
92025A SHIM,T=0.5MM 92025-3706
92025B SHIM,T=1.0MM 92025-3707
92025C SHIM,T=1.5MM 92025-3708
92075 DAMPER,ENGINE MOUNT 92075-3724
