KAWASAKI
JS550
1984

Spare Part Category
Show me all the part categories of the model
KAWASAKI - JS550 1984 - Electrical - ELECTRIC CASE
Electrical
ELECTRIC CASE
No Part Part No Notes
1 CASE-ELECTRIC,FRONT 59416-3004-YR
2 CASE-ELECTRIC,REAR 59416-3005-YR
3 GASKET,ELECTRIC CASE 11009-3781
4 CLAMP,L=100 92037-3736
5 TUBE,VINYL,5X73 92059-3017
6 BOLT,HEX HEAD,6X25 110R0625
7 WASHER 411S0600
8 JOINT 59071-3001
9 "0" RING,16MM 670B2016
10 CASE,FUEL TAP 32099-3752
11 BOLT,6X80 110R0680
12 WASHER 411S0600
13 IGNITER 21119-3016
14 SCREW PAN HEAD 6X20 220B0620
15 WASHER PLAIN 6MM 410B0600
16 CAP 11012-3005
17 GROMMET 92071-527
18 GROMMET 92071-529
19 GROMMET 92071-517
20 CAP SPARK PLUG 21130-009
21 SPRING-SPARK PLUG CAP 92101-001
22 COVER,PLUG 92071-501
23 REGULATOR-VOLTAGE 21066-3003
24 SCREW PAN HEAD 6X12 220B0612
25 WASHER PLAIN 6MM 410B0600
26 CONNECTOR,CORD 59221-505
27 RELAY 27034-3002
28 SCREW PAN HEAD 6X45 220B0645
29 WASHER PLAIN 6MM 410B0600
30 COLLAR 92027-3013
31 RELAY 27034-3004
32 SCREW PAN HEAD 6X16 220B0616
33 WASHER 410S0600
34 SPARK PLUG B7ES 92070-3003
35 SWITCH,SOLENOID 27010-3007
36 WASHER,10.5X24X2.5 92022-3035
37 WASHER PLAIN 10MM 410B1000
38 GROMMET 92071-3004
39 WASHER 92022-3036
40 WASHER 92022-553
41 NUT,6M/M 311R0600
42 WASHER 411S0600
43 WIRE-LEAD,L=230 26011-3003
44 WIRE-LEAD 26011-3008
45 WIRE-LEAD,BATTERY(+) 26011-3778
46 WIRE-LEAD,L=340 26011-3005
47 CAP 11012-3004
48 PANEL-CONTROL 59226-3702
49 SCREW,CNTSNK HEAD8X22 92009-3004
50 WIRE-LEAD,BATTERY(-) 26011-3776
51 FB BAT FB16L-B 26012-3003
52 CAP-BATTERY TERMINAL 59176-501
53 PLATE-BATTERY 13169-3014
54 CUSHION,BATTERY 92075-509
55 BAND,BATTERY 92072-512
