KAWASAKI
JS550
1986

Spare Part Category
Show me all the part categories of the model
KAWASAKI - JS550 1986 - Engine/Transmission - DRIVE SHAFT
Engine/Transmission
DRIVE SHAFT
No Part Part No Notes
1 HOUSING-BEARING 41046-502
2 SEAL-OIL,AC1799EX 92050-501
3 SHAFT,DRIVE 13107-3008
4 BEARING-BALL,#6305C3 601B6305
5 COLLAR 92027-502
6 SLEEVE,BEARING 42036-501
7 COVER,BEARING 14025-3008
8 RING-O 92055-501
9 SEAL-OIL,AC1799EX 92050-501
10 BOLT,8X25 110R0825
11 WASHER-SPRING,8MM 461S0800
12 WASHER-PLAIN,8MM 411S0800
13 SHIM,T=0.15 92025-502
13A SHIM,T=0.3 92025-503
14 FITTING,GREASE 92005-501
15 PIN-DOWEL 551R0612
16 COUPLING 42034-3005
17 BOLT,8X25 110R0825
18 WASHER-SPRING,8MM 461S0800
19 WASHER-PLAIN,8MM 411S0800
20 DAMPER,COUPLING 92075-520
21 COVER,COUPLING 59036-567
22 BOLT,6X16 110R0616
23 WASHER-SPRING,6MM 461S0600
24 WASHER-PLAIN,6MM 411S0600
25 SHIM,T=0.3MM 92025-3701
25A SHIM,T=0.5MM 92025-3702
25B SHIM,T=1.0MM 92025-3703
25C SHIM,T=1.5MM 92025-3704
