KAWASAKI
JS400
1976

Spare Part Category
Show me all the part categories of the model
KAWASAKI - JS400 1976 - Engine/Transmission - DRIVE SHAFT/JET PUMP
Engine/Transmission
DRIVE SHAFT/JET PUMP
No Part Part No Notes
1 COUPLING ASSY,DRIVER 42053-3004
2 WASHER 92022-514
3 BOLT,1/2 INCHX27 92003-537
4 RUBBER,COUPLING 92075-501
5 COVER,COUPLING 59036-567
6 BOLT 6X12 110R0612
7 WASHER-SPRING,6MM 461S0600
8 WASHER 411S0600
9 COUPLING,DRIVEN 42034-501
10 SLEEVE,BEARING 42036-501
11 SEAL,OIL AC1799EX 92050-501
12 COVER,BEARING 14025-3008
13 BOLT,8X25 110R0825
14 WASHER SPRING 8MM 461S0800
15 WASHER 411S0800
16 "0" RING 92055-501
17 SHIM 0.15T 92025-502
17 SHIM 0.3T 92025-503
18 BEARING BALL #6305 601B6305
19 COLLAR 92027-502
20 SEAL,OIL AC1799EX 92050-501
21 HOLDER 41046-502
22 PIN,DOWEL 551R0612
23 NIPPLE,GREASE 92005-501
24 BOLT,8X25 110R0825
25 WASHER SPRING 8MM 461S0800
26 WASHER 411S0800
27 SHAFT,DRIVE 59111-515
28 IMPELLER 59256-504
29 RING,SNAP 92036-502
30 SEAL,OIL SC20367 92050-503
31 SEAL,OIL SCY20368 92050-502
32 BUSH 92028-503
33 CASE-PUMP 59336-3701
34 BOLT-SOCKET 120R1025
35 WASHER-SPRING,10MM 461S1000
36 WASHER 411S1000
37 NUT 10M/M 92015-527
38 COVER,PUMP 59036-558
39 NIPPLE,GREASE 92005-501
40 SHIM 0.15T 92025-504
40 SHIM 0.3T 92025-505
40 SHIM 0.5T 92025-506
40 SHIM 1.0T 92025-507
41 SCREW 6X16 92011-563
42 WASHER 92095-512
43 NOZZLE,PUMP 59136-3001
44 BOLT 8X22 92003-528
45 WASHER SPRING 8MM 461S0800
46 WASHER 92022-562
47 JOINT-BALL 59266-3707
48 WASHER-SPRING,6MM 461S0600
49 WASHER 92022-567
50 NOZZLE-STRG 59476-3702
51 BOLT 6X11 92003-532
52 GRATE 59366-3001
53 SCREW 6X16 92011-563
54 WASHER 92095-512
55 BUSH 92028-511
