KAWASAKI
ULTRA 130
2003

Spare Part Category
Show me all the part categories of the model
KAWASAKI - ULTRA 130 2003 - Engine/Transmission - Crankcase
Engine/Transmission
Crankcase
No Part Part No Notes
172 BOLT-STUD 172R0620
172A BOLT-STUD 172R0630
175 BOLT-STUD-FINE 175R1035
551 PIN-DOWEL 551R0612
551A PIN-DOWEL 551R1012
11060 GASKET,REED VALVE 11060-3717
11060A GASKET,REED VALVE 11060-3757
12021 VALVE-ASSY-REED 12021-3713
12022 VALVE-REED 12022-3711
14001 SET-CRANKCASE 14001-5385
16087 VALVE-CHECK 16087-3713
92002 BOLT,6X30 92002-3726
92004 STUD,CRANK CASE 92004-3752
92009 SCREW,REED VALVE 92009-1014
92028 BUSHING 92028-3718
92066 PLUG 92066-1213
92150 BOLT,8X65 92150-3708
