Engine/Transmission
|
|
Carburetor Parts
|
|
| No |
Part |
Part No |
Notes |
|
11060
|
GASKET,DIAPHRAGM COVER |
11060-3789 |
|
|
13070
|
GUIDE,VACUUM VALVE |
13070-3727 |
|
|
14041
|
COVER-COMP,MIXING |
14041-1100 |
|
|
14090
|
COVER,DIAPHRAGM |
14090-3816 |
|
|
16014
|
SCREW-PILOT AIR |
16014-3701 |
|
|
16017
|
JET-NEEDLE,N8DC |
16017-3705 |
|
|
16030
|
VALVE-FLOAT |
16030-3704 |
|
|
16055
|
ARM-FLOAT |
16055-3703 |
|
|
16087
|
VALVE-CHECK |
16087-3706 |
|
|
16126
|
VALVE,VACUUM |
16126-3706 |
|
|
16158
|
JET-SLOW,#48 |
16158-3724 |
|
|
16158A
|
JET-SLOW,#45 |
16158-3725 |
16158A - JET-SLOW,#45
*|*(OPTION)
|
|
32099
|
CASE,JET |
32099-3833 |
|
|
43028
|
DIAPHRAGM,CARBURETOR |
43028-3711 |
|
|
43049
|
PACKING,JET CASE |
43049-3713 |
|
|
59336
|
CASE-PUMP,DIAPHRAGM |
59336-3717 |
|
|
92009
|
SCREW |
92009-1771 |
|
|
92009A
|
SCREW,3X8 |
92009-3712 |
|
|
92009B
|
SCREW,4X8 |
92009-3804 |
|
|
92009C
|
SCREW,VALVE GUIDE |
92009-3839 |
|
|
92009D
|
SCREW,DIAPHRAGM COVER |
92009-3840 |
|
|
92009E
|
SCREW,MIXING COVER |
92009-3841 |
|
|
92009F
|
SCREW,6X16 |
92009-3865 |
|
|
92055
|
RING-O,VACUUM VALVE GUIDE |
92055-3749 |
|
|
92063
|
JET-MAIN,#165 |
92063-3720 |
|
|
92063A
|
JET-MAIN,#155 |
92063-3723 |
92063A - JET-MAIN,#155
*|*(OPTION)
|
|
92144
|
SPRING,FLOAT ARM |
92144-3764 |
|
|
92145
|
SPRING,VALVE |
92145-3714 |
|
|
92145A
|
SPRING,JET NEEDLE |
92145-3715 |
|
|
92152
|
COLLAR,JET NEEDLE |
92152-3706 |
|
|
92200
|
WASHER,VALVE GUIDE |
92200-3772 |
|
|
92200A
|
WASHER,JET NEEDLE |
92200-3773 |
|
|
92200B
|
WASHER,JET NEEDLE COLLAR |
92200-3774 |
|
|
|
|
