KAWASAKI
ULTRA 150
2003

Spare Part Category
Show me all the part categories of the model
KAWASAKI - ULTRA 150 2003 - Engine/Transmission - Carburetor
Engine/Transmission
Carburetor
No Part Part No Notes
11052 BRACKET 11052-3771
13271 PLATE 13271-3846
14044 HOLDER-CABLE,CARBURETOR 14044-3744
14079 HOLDER-ASSY,SENSOR 14079-3722
15003 CARBURETOR-ASSY 15003-3740
16021 SCREW-THROTTLE STOP 16021-3704
16021A SCREW-THROTTLE STOP 16021-3709
16172 ACTUATOR 16172-3703
21176 SENSOR 21176-3739
54010 CABLE 54010-3715
59071 JOINT 59071-3766
59091 PULLEY 59091-3708
92002 BOLT,6X25 92002-3714
92002A BOLT,6X16 92002-3728
92009 SCREW,4X6 92009-3786
92009A SCREW,SENSOR 92009-3863
92055 RING-O 92055-1246
92055A RING-O,SENSOR 92055-1574
92072 BAND 92072-3848
92072A BAND 92072-3874
92143 COLLAR 92143-1907
92144 SPRING,ADJUST SCREW 92144-3704
92144A SPRING,THROTTLE STOP SCREW 92144-3745
92150 BOLT,6X18 92150-3729
92151 BOLT,5X10 92151-3749
92152 COLLAR,SENSOR 92152-3721
92191 TUBE,PULSE 92191-3838
