Engine/Transmission
|
|
CRANKSHAFT/PISTONS
|
|
| No |
Part |
Part No |
Notes |
|
1
|
PISTON-ENGINE,STD |
13001-2094 |
|
|
1A
|
PISTON-ENGINE L,O/S 0.5MM |
13029-2077 |
|
|
2
|
RING-PISTON TOP,STD |
13003-2129 |
|
|
2A
|
RING-PISTON TOP,O/S 0.5MM |
13003-2130 |
|
|
3
|
PIN-PISTON |
13002-504 |
|
|
4
|
RING-SNAP |
92036-507 |
|
|
5
|
BEARING-NEEDLE |
92046-503 |
|
|
6
|
CRANKSHAFT-COMP |
13031-2051 |
|
|
7
|
SHIM,T=1.0MM |
92025-532 |
|
|
8
|
SHIM,T=0.1 |
92025-513 |
|
|
8A
|
SHIM,T=0.2 |
92025-518 |
|
|
8B
|
SHIM,T=0.3 |
92025-523 |
|
|
8C
|
SHIM,T=0.4 |
92025-527 |
|
|
8D
|
SHIM,T=0.5 |
92025-530 |
|
|
8E
|
SHIM,T=0.6 |
92025-533 |
|
|
9
|
BEARING-BALL |
92045-3010 |
|
|
10
|
RING-O |
92055-504 |
|
|
11
|
PIN-DOWEL |
551A0410 |
|
|
12
|
SLEEVE,CRANKSHAFT OUT |
42036-3007 |
|
|
13
|
RING-O,22MM |
92055-3009 |
|
|
14
|
SEAL-OIL,OIL,TCY306210 |
92049-3005 |
|
|
15
|
SEAL-OIL,OIL,DCY30629 |
92049-3006 |
|
|
16
|
SEAL-OIL,TCY306210 |
92050-507 |
|
|
17
|
WASHER,CRANK,RH |
92022-3021 |
|
|
18
|
COUPLING |
42034-3005 |
|
|
19
|
WASHER,18.5X38X4 |
92022-3028 |
|
|
20
|
KEY-WOODRUFF |
510A5200 |
|
|
21
|
WASHER,LOCK,20MM |
92022-569 |
|
|
22
|
NUT,20MM |
92015-535 |
|
|
|
|
