Engine/Transmission
|
CARBURETOR
|
|
No |
Part |
Part No |
Notes |
1A
|
CARBURETOR-ASSY |
15001-3738 |
|
2
|
NUT,THROTTLE LEVER |
92015-3717 |
|
3
|
WASHER,THROTTLE LEVER |
92022-3722 |
|
4
|
LEVER-ASSY-THROTTLE,THROTTLE |
39074-3704 |
|
5
|
COLLAR,THROTTLE SHAFT |
92027-2098 |
|
6
|
LEVER-THROTTLE,STOP |
39075-2104 |
|
7
|
SPRING,THROTTLE SHAFT |
92081-2336 |
|
8
|
BUSHING,CARBURETOR |
92028-514 |
|
14
|
SCREW,THROTTLE STOP |
23013-2051 |
|
15
|
GASKET |
92065-528 |
|
16
|
SPRING,THROTTLE CABLE BRACKET |
16040-022 |
|
18
|
WASHER |
92022-537 |
|
19
|
SPRING |
92081-528 |
|
20
|
RING-O |
92055-510 |
|
22
|
RING-O |
92055-511 |
|
23
|
SPRING |
92081-534 |
|
25
|
BOLT,4X8 |
92001-3026 |
|
26
|
TERMINAL,CHOKE SHAFT |
21169-3008 |
|
27
|
SHAFT-CARBURETOR,CHOKE |
16041-2136 |
|
28
|
WASHER,PLAIN,NYLON |
92022-3020 |
|
29
|
RING-SNAP,5MM,SUS304 |
92033-3004 |
|
30
|
SPRING,CHOKE SHAFT |
92081-2337 |
|
31
|
COLLAR,CHOKE SHAFT |
92027-2097 |
|
32
|
PACKING,CHOKE SHAFT |
11009-2465 |
|
33
|
WASHER,CHOKE SHAFT |
92022-2221 |
|
34
|
PIN,SNAP |
92043-2121 |
|
37
|
GASKET,FLOAT VALVE SEAT |
16029-004 |
|
38
|
VALVE-FLOAT,2.0MM |
16030-2066 |
|
39
|
SPRING |
92081-536 |
|
40
|
PIN,FLOAT |
16032-006 |
|
41
|
PLATE |
59001-506 |
|
42A
|
SCREW |
92009-3714 |
|
43
|
GASKET |
92065-544 |
|
44
|
DIAPHRAGM,CHECK SHEET |
51069-501 |
|
45
|
BRACKET,CARBURETOR |
59086-541 |
|
46
|
DIAPHRAGM,MAIN,CARB |
51069-502 |
|
47
|
GASKET |
92065-531 |
|
48
|
CASE,PUMP |
59021-514 |
|
49
|
GASKET |
11009-3036 |
|
50
|
DIAPHRAGM,PUMP,CARBURETOR |
43028-3002 |
|
51
|
CASE-PUMP |
59336-3002 |
|
52
|
GASKET |
92065-532 |
|
53
|
DIAPHRAGM,PUMP,CARBURETOR |
43028-3001 |
|
54
|
CASE-PUMP |
59336-3003 |
|
55
|
SCREW,4X30 |
92011-515 |
|
56
|
GASKET |
92065-526 |
|
57
|
COVER,CARBURETOR |
59036-530 |
|
58
|
SCREW,4X12 |
92011-510 |
|
59
|
CAP,JET NEEDLE |
11012-3739 |
|
60
|
NEEDLE-JET |
16009-3708 |
|
61
|
NEEDLE-JET,HIGH SPEED |
16009-3709 |
|
62
|
NEEDLE-JET |
16009-3710 |
|
|
|
|
