KAWASAKI
JS400
1976

Spare Part Category
Show me all the part categories of the model
KAWASAKI - JS400 1976 - Engine/Transmission - CARBURETOR
Engine/Transmission
CARBURETOR
No Part Part No Notes
1 CARBURETOR 16001-3003-YR
2 .SPRING 92081-529
3 .GASKET 92065-529
5 .THROTTLE SHAFT ASSY 59111-519
6 .SPRING,CABLE PULLY 16040-022
7 .SCREW,4X20 92009-3009
8 .BOLT,4X8 92001-3026
9 .SPRING 92081-525
11 .SCREW,LOW SPEED 59271-506
12 .SPRING 92081-528
13 .WASHER 92022-537
14 ."0" RING 92055-510
15 .SCREW 3X5 92011-517
16 .VALVE,CHOKE 16126-3001
17 ."0" RING,DRAIN PLUG 92055-1093
18 .WASHER 92065-528
19 .SPRING 92081-534
20 .SCREW,HIGH SPEED 59271-507
21 .SCREW 2.3X3 92011-506
22 .GASKET 92065-520
23 .SCREW 4X30 92011-515
24 .SCREW 3X7 92011-516
25 .VALVE,THROTTLE 16025-503
26 .FLOAT PIN 16032-006
27 .ARM 59001-506
28 .SCREW 3X7 92011-516
29 .WASHER FLOAT VLV SEAT 16029-004
30 .VALVE-SEAT 16030-503
31 .SPRING 92081-536
32 .DIAPHRAGM,MAIN 51069-502
33 .GASKET 11060-3704
34 .BODY,DIAPHRAGM(1) 59021-514
35 .DIAPHRAGM,PUMP 43028-3002
36 .BODY,DIAPHRAGM(2) 59336-3002
37 .GASKET 11060-3705
38 .DIAPHRAGM,PUMP 43028-3001
39 .BODY,DIAPHRAGM(3) 59336-3003
40 .GASKET 92065-526
41 .FILTER 14037-504
42 .SCREW 4X12 92011-510
43 .COVER-CARB. SIDE 59036-530
44 .GASKET 92065-530
45 .DIAPHRAGM,CHECK SEAT 51069-501
46 .PLATE 59086-509
47 .SCREW 3X7 92011-516
48 .BANJO-CARB 59071-505
49 .GASKET-BANJO BOLT 92065-078
50 .BOLT,BANJO 92003-521
